ZK-660FC Fully Automatic Box Folding Machine
The ZK-660FC hard box production machine features a servo control system, programmable motion control system, photoelectric servo positioning system, and human-machine interface control system. The forming section combines servo drive and mechanical cams, featuring high production efficiency, stable operation, durability, and low noise. It achieves integrated operations such as automatic paper feeding, gluing, positioning, wrapping, full folding, and folding molding, meeting the requirements of high-end cartons. Production speed can reach up to 35 units per minute.
1. Servo control system: ensures precise and efficient operation.
2. Programmable motion control system: Offers flexible and customizable operation settings.
3. Optoelectronic Servo Positioning System: Achieves precise positioning to ensure high-quality production results.
4. Human-Machine Interface Control System: Simplifies user operation and improves convenience.
5. Servo drive combined with mechanical cam: Provides high production efficiency, stability, durability, and low noise.
6. Automatic paper loading and gluing functions: Simplify production processes and improve efficiency.
7. Full ear folding and inward folding forming: Completing multiple complex forming actions at once.
8. High production speed: up to 35 pieces per minute.
1. Box length less than 125mm requires replacement of small-size accessories.
2. The box size specification is limited by the size of the tissue paper.
3. Optional online adhesive viscosity testing system.
4. Our company does not provide air compressors.
5. Several factors affecting machine speed: raw materials, glue, and operator proficiency.
6. Due to continuous innovation in product design, the above data is for reference only; Changes are subject to change without prior notice.
